AVER VC520 PRO กล้อง Video Conference สำหรับห้องประชุมแบบ FULL HD 1080P , True WDR, optical zoom 12x พร้อม Speakerphone

From ฿70,620

VC520 PRO EXPANSION MICROPHONE เพียง 9,897.- (ปกติ 19,795.-)VC520 PRO EXPANSION MICROPHONE เพียง 9,897.- (ปกติ 19,795.-)
VC520 PRO EXPANSION SPEAKERPHONE เพียง 12,580.- (ปกติ 25,145.-)VC520 PRO EXPANSION SPEAKERPHONE เพียง 12,580.- (ปกติ 25,145.-)
  • ได้รับสินค้า 3 - 7 วัน (ขึ้นอยู่กับที่อยู่จัดส่ง)

หมายเหตุ : กรุณาเช็ค Stock สินค้ากับเจ้าหน้าที่ ก่อนสั่งซื้อทุกครั้ง

กล้อง Video Conference AVER VC520 PRO สำหรับห้องประชุมแบบ FULL HD 1080P , True WDR, optical zoom 12x พร้อม Expansion Speakers / Microphones จากแบรนด์ AVER

Professional conferencing system

Professional conferencing system for mid-to-large rooms

The VC520 Pro is equipped with a 12X optical zoom and daisy-chain speakerphone that deliver a lifelike audiovisual experience. With 1080p HD quality, Sony True WDR, and IP-based management features, the VC520 Pro is the professional conferencing system your enterprise needs.

Perfect Audio for Professional Conferencing

Experience lifelike audio in various sizes of meeting rooms with the VC520 Pro. The speakerphone’s pickup range is up to 15 ft., or you can daisy-chain two additional speakerphones and reach up to 45 ft. Touch controls make it easy to adjust or mute the volume, and echo cancellation ensures a steady audio experience. You can also connect extra microphones for ultra-clear voice pickup.

SmartFrame Captures Everyone in Seconds

Improve productivity by starting meetings instantly. The VC520 Pro processes facial recognition to capture everyone on-screen in seconds and automatically re-frames whenever someone walks in or out of the room.

Professional Clarity with 12X Optical Zoom

Show every detail precisely and smoothly to enhance communication. The VC520 Pro is embedded with a 12X true optical zoom and multi-coated auto-focus optics to present complex product details in full HD 1080p quality.

Hold Meetings Anywhere with True WDR

Maintain constant clarity in high-contrast backlight environments. The VC520 Pro’s embedded Sony sensor provides True WDR up to 120dB, controling the exposure and light values of pixels in any lighting.

Video Streaming and Remote Control via IP-Based Management

The VC520 Pro features advanced centralized management through the Chrome browser. Remotely control the camera and share on Facebook or YouTube with H.264 and AAC-LC RTSP/RTMP streaming in 1080p at 60fps via USB 3.1.

Hardware Spec

Camera Back Panel

  1. Available with VC520 Pro Speakerphone set
  2. USB 3.1 Type-B
  3. RS232 in/out
  4. LAN for IP streaming/remote access
  5. DC 12V

Speakerphone Back Panel

  1. Daisy-chain up to 3 speakerphones or 4 microphones
  2. Phone in
  3. Line out
  4. Available with VC520 Pro camera set
น้ำหนัก 5.4 kg
ขนาด 259 × 259 × 349 mm


VC520 PRO EXPANSION MICROPHONE เพียง 9,897.- (ปกติ 19,795.-), VC520 PRO EXPANSION SPEAKERPHONE เพียง 12,580.- (ปกติ 25,145.-), ไม่แลกซื้อ



  • Sony super-low-light 2M pixel sensor for clear and natural imaging in low-light conditions
  • Resolution: (16:9) 1920 x 1080, 1600 x 900, 1280 x 720, 960 x 540, 848 x 480, 800 x 448, 640 x 360, 424 x 240, 320 x 180; (4:3) 800 x 600, 640 x 480, 480 x 360, 320 x 240 at 60, 30, 15fps
  • SmartFrame for automatic FOV adjustment to fit all participants
  • True WDR up to 120dB: Superb backlight compensation technology for optimizing light balance in high-contrast conditions
  • Zoom: 18X total zoom (12X optical zoom)
  • Wide field of view (DFOV): 82°
  • Lens focal length: 3.9 mm (wide) ~ 47.3 mm (tele)
  • Lens F#: 1.8 (wide) ~ 2.8 (tele)
  • Mirror, Flip, AE, white balance: aut o, manual override via PTZApp
  • Minimum focus distance: 1.5 m
  • Standard tripod screw holes and Kensington slot

Video Format

  • YUV, MJPEG, H.264
  • Network video compression format: H.264
  • Network protocols: RTSP, RTMP

Audio Format

  • AAC-LC
  • Network protocol: RTSP, RTMP


  • 12V/5A power adaptor
  • Mini DIN9 for RS232 in & out connection (VISCA control panel and camera daisy-chain)
  • USB 3.1 Type-B connector
  • IP (RJ45)


  • IR remote control
  • VISCA/Pelco-P/Pelco-D via RS232 (128 preset points via VISCA command)
  • Remote side: VISCA over IP, IP (RJ45)
  • UVC/UAC plug-and-play
  • WebUI: Browser IP access via Chrome (does not support Internet Explorer)
  • PTZApp

System Requirements

  • Windows® 7/10

  • Mac OS X 10.13 or higher
  • Google Chromebook version 76.0.3809.102 or later
  • Android 6 or higher

Web page browser requirement

  • Chrome: version 76.x or above
  • Firefox: version 69 or above
  • IE: Not support

Free Applications for Meeting Collaboration (Windows® and Mac)EZManager: Camera Central Management software

  • Remotely group FW/SW upgrades, control the camera, and configure settings


  • Upgrade firmware automatically or manually
  • Control camera
  • Set parameters and adjust camera image
  • Diagnose operating status
  • View live video


  • Real-time streaming / annotating / snapshots / video recordin


  • Package dimensions: 259 x 259 x 349 mm
  • Package weight: 5.4 kg
  • Camera: 142.7 x 153 x 182 mm/1.45 kg
  • Speakerphone: 220 x 181.5 x 49.5 mm/0.85 kg
  • Remote control: 200 x 50 x 21 mm/0.09 kg

Optional Accessories

  • Mini DIN9 to RS232 adapter
  • Expansion Speakerphone
  • Expansion Microphone
  • Foldable TV mount

Motorized Pan & Tilt Movement

  • Pan: ±170°
  • Tilt: +90° (up) -30° (down)
  • 10 camera presets (through remote control)
  • Fast and quiet pan & tilt movement


  • Full duplex microphone array with echo cancellation
  • Advanced noise suppression
  • Dual-microphone array
  • 3.5 mm phone-in jack
  • 3.5 mm line out
  • Speaker volume: Adjustable to 90dB SPL at 0.5 m
  • Touch controls for volume down/up, mute, phone input, call, and hang-up
  • Bridge phone-in and USB into one call
  • Security: Kensington slot


  • 10/100/1000 Mbps


  • 3.1 Gen 1 Type-B, backward compatible with USB 2.0
  • UVC (USB video class) 1.1
  • UAC (USB audio class) 1.0


  • Camera wall-mount bracket included
  • Optional foldable TV mount

Hardware Specs

  • 3.2 GHz Intel® Core™ i5-4460 Processor or higher
  • 4 GB RAM or more
  • USB 3.1 port, backward compatible with USB 2.0 port

Power Supply

  • AC 100V ~ 240V, 50/60 Hz
  • Consumption: 12V, 5A

Environmental Data

  • Operation temperature: 0°C ~ 40°C
  • Operation humidity: 20% ~ 80%
  • Storage temperature: -20°C ~ 60°C
  • Storage humidity: 20% ~ 80%
