| Height |
88.1mm (3.47″) |
| Amplifier Gain |
32 dB (Lo-Z), 33 dB (70V), 36dB ((100V)) |
| Analog Inputs |
4, electronically balanced, Phoenix-type |
| Audio Network |
No |
| CAN Bus Interface |
Optional (RCM-810 card) |
| Continuous Rated Power (1 kHz, THD 1%) 100v |
1000Watts |
| Continuous Rated Power (1 kHz, THD 1%) 2Ω |
1000Watts |
| Continuous Rated Power (1 kHz, THD 1%) 4Ω |
1000Watts |
| Continuous Rated Power (1 kHz, THD 1%) 70v |
1000Watts |
| Continuous Rated Power (1 kHz, THD 1%) 8Ω |
500Watts |
| Continuous Rated Power (20-20 kHz, THD<0,2%) 100v |
900Watts |
| Continuous Rated Power (20-20 kHz, THD<0,2%) 4Ω |
900Watts |
| Continuous Rated Power (20-20 kHz, THD<0,2%) 70v |
900Watts |
| Continuous Rated Power (20-20 kHz, THD<0,2%) 8Ω |
450Watts |
| Cooling |
Front-to-Rear, continuously variable fans |
| DIM 30 |
0.02% |
| Electronics Type |
Amplifier |
| Frequency Response (-3 dB) |
15 Hz-30 kHz |
| Impedance |
2/4/8/8 VLD/70 V/100VΩ |
| Input Impedance (Balanced) |
20kΩ |
| Input Sensitivity |
0 dBu (.775V)-2ω, +3 dBu (1.1V)-4/8ω, +6 dBu (1.55) 70V/100V |
| Intermodulation Distortion (SMPTE) |
0.05% |
| Mains Voltage |
220 – 240 V, 50 – 60 Hz or 120 V, 50 – 60 Hz, 50 – 60 Hz |
| Maximum Bridged Output 4Ω |
2000Watts |
| Maximum Bridged Output 8Ω |
2000Watts |
| Maximum Input Voltage |
+22 (9.76 Vrms) |
| Network Control (IRIS-Net) |
Optional (RCM-810 card) |
| Signal-to-Noise Ratio (A-weighted) |
103dB |
| Slew Rate |
28V/µs |
| Topology |
Class-D |
| Total Harmonic Distortion |
0.05% |
| Variable Load Drive (VLD) |
Yes |
