Dante Network Card For NXAMP. NEXO NXDT104 MK2 รับ 4 ออดิโอสตรีม (24 บิต / 44.1 – 96 kHz) ในรูปแบบ DanteTM จากแบรนด์ NEXO
NEXO NXDT104 MK2
Dante™ Network card for NXAMP
The DPU optimises the NXAMP or NXAMPMK2’s channel by channel preset selection by automatically routing its outputs to any of six output connectors on the DPU front panel. Cabinet names and bridging status are displayed alongside each output, making it easy to wire the system.
คุณสมบัติ
- Receives 4 audio streams (24 bits / 44.1 – 96 kHz) in DanteTM format
- Remote control from any computer on a local area network using TCP/IP commands.
- Unique 3-port design can be used: – As an integrated 3 port gigabit switch – As two Dante™ redundant port plus an optional 3rd port for additional remote control
สเปค
| DIGITAL AUDIO FORMAT | |
| Digital audio type | DanteTM networks |
| Media type | Standard TCP/IP over Ethernet network, minimum 100 Mb, recommended 1 Gb |
| Number of channels | 4 channels from network to NXAMP |
| Resolution / Sample Rate | 24 bits / 44.1 – 96 kHz |
| Latency | 0.15 ms to 5.0 ms (typical 1 ms) |
| REMOTE CONTROL FORMAT | |
| Network format | Standard TCP/IP |
| Device addressing | Automatic, based on IP address with Zeroconf |
| FRONT PANEL FEATURES | |
| Digital audio connectors | 2 shielded Neutrik Ethercon |
| Additional port | RJ45 for additional remote control |
| LEDs on digital audio ports | Link/Act and Speed on each port |
| LEDs on remote port | Link and activity |
| GENERAL SPECIFICATIONS | |
| Power supply | + 3.3 Volts, 7 W from NEXO slot |
| Dimensions (W x D x H) | 120 x 160 x 40 mm (NXAMP slot) |
| Weight | 200 g |
| EMC certification | CE, FCC, ICES |
| Green Status | ROHS and REACH |
