TASCAM MH-8 HEADPHONE AMP แอมป์หูฟัง 8 ชาแนล
฿20,437 (รวม VAT 7% แล้ว)
เช็ค Stock และราคาสินค้า กับเจ้าหน้าที่ก่อนสั่งซื้อทุกครั้ง
TASCAM MH-8 8-channel Headphone Amplifier
TASCAM MH-8 HEADPHONE AMP แอมป์หูฟัง 8 ชาแนล MH-8 Headphone amplifier จากแบรนด์ TASCAM
For the ultimate in routing flexibility and power, nothing beats the MH-8 headphone amp from TASCAM
TASCAM’s MH-8 is the ultimate headphone amplifier for studio, stage and installation. Each of the eight stereo outputs gets 250mW per side with three switchable sources available. Two stereo inputs can be shared to any of the outputs, and individual stereo direct inputs are available for each of the eight channels. A headphone out can select any one of these inputs, or mix several together. A set of foldback outputs allow you to chain other MH-8s into a system.
คุณสมบัติ
- 8 stereo 1/4″ headphone outputs
- 250mW + 250mW at 32Ω per channel
- Each headphone output switchable to input 1, input 2 and direct input source (or a combination of the three)
- Master input gain controls
- 16 1/4″ TRS balanced direct inputs
- 4 XLR balanced inputs (CH1 & CH2)
- 2 1/4″ TRS balanced inputs (CH1)
- 2 RCA unbalanced inputs (CH2)
- 4 TRS balanced foldback outputs
- Ground lift switch and terminal
Applications
- Music retailer listening station
- Recording studio monitoring
- In-ear stage monitor distribution
- Tradeshow headphone distribution
สเปค
| Audio Inputs/Outputs | |
| INPUT 1 and 2 | |
| Connector | XLR-3-31 (1: GND, 2: HOT: 3: COLD) × 2 pairs |
| Input impedance | 56kΩ |
| Nominal input level | +4dBu (1.23mV) |
| Maximum input level | +24dBu (12.3V) |
| INPUT 1 | |
| Connector | 1/4″ (6.3mm) TRS Phone jack (Top: HOT, Ring: COLD, Sleeve: GND) × 1 pairs |
| Input impedance | 56kΩ |
| Nominal input level | +4dBu (1.23V) |
| Maximum input level | +24dBu (12.3V) |
| INPUT 2 | |
| Connector | RCA Pin jack × 1 pair |
| Input impedance | 22kΩ |
| Nominal input level | –10dBu (0.3V) |
| Maximum input level | +10dBu (3.16V) |
| DIRECT INPUT | |
| Connector | 1/4″ (6.3mm) TRS Phone jack (Top: HOT, Ring: COLD, Sleeve: GND) × 8 pairs |
| Input impedance | 56kΩ |
| Nominal input level | +4dBu (1.23V) |
| Maximum input level | +24dBu (12.3V) |
| FOLDBACK OUT | |
| Connector | 1/4″ (6.3mm) TRS Phone jack (Top: HOT, Ring: COLD, Sleeve: GND) × 2 pairs |
| Input impedance | 94kΩ |
| Nominal input level | +4dBu (1.23V) |
| Maximum input level | +24dBu (12.3V) |
| PHONES OUT | |
| Connector | 1/4″ (6.3mm) Stereo Phone jack × 8 |
| Maximum output level | 250mW + 250mW (32Ω) |
| Power | AC 100 – 240V, 50/60Hz |
| Power consumption | 36W |
| Dimensions (W×H×D) | 19.0″ × 1.73″ × 11.0″ / 482 × 44 × 280 mm |
| Weight | 8.4 lbs. / 3.8 kg |
| Included items | Power cord, Rackmounting screw kit, Owner’s manual (with warranty) |
Audio performance
| Frequency response | |
| PHONES out | 20Hz to 50kHz/100mW, 32Ω ±3dB |
| FOLDBACK out | 10Hz to 100kHz ±3dB |
| S/N ratio | |
| PHONES out | 85dB or greater (A-weighted, 20kHz, LPF) |
| FOLDBACK out | 90dB or greater (A-weighted, 20kHz, LPF) |
| THD | |
| PHONES out | 0.05% or less (when outputting 100mW + 100mW 32Ω, 20Hz HPF and 20kHz LPF) |
| FOLDBACK out | 0.07% or less (20Hz HPF and 20kHz LPF) |
| Channel separation | |
| PHONES out | 50dB or greater (within a channel, A-weighted, 20kHz LPF, 1kHz nominal inout and output, 32Ω termination) |
| FOLDBACK out | 90dB or greater (A-weighted, 20kHz LPF, 1kHz nominal inout and output, 600Ω termination) |
| Crosstalk | |
| PHONES out | 65dB or greater (A-weighted, 20kHz LPF, 1kHz nominal inout and output, 32Ω termination) |
| ยี่ห้อ |
|---|
