Ultra-High Precision 24-Bit/96 kHz Equalizer, Analyzer, Feedback Destroyer and Mastering Processor
ULTRACURVE PRO DEQ2496
The DEQ2496 is a high-precision digital 24-bit/ 96 kHz EQ/RTA mastering processor, ideal for sophisticated live sound trouble-shooting or audiophile mastering. Whether you’re putting the finishing touches on recorded material or creating an optimal live sound for a multi-way PA, the DEQ2496 is built to provide meticulous control.
Equalization. Dynamics. Feedback Correction.
You can have it all with the DEQ2496. How about automatic FFT analysis with Auto EQ? We added that too. The DEQ2496 is a whole rack of ultra-flexible equalization options, dynamics and time-correction solutions, all designed to optimize your rig’s sound quality like no other single piece of processing gear. Consider the DEQ2496 your audio engineer’s Swiss Army Knife – here are a just few examples: Dual 31-band Graphic Equalizers (stereo linkable) Dual 31-band Virtual Paragraphic Equalizers (stereo linkable) Dual 10-band Parametric EQ’s per stereo side Dynamically-activated EQ Feedback Destroyer with Learning Mode Stereo Imager Compressor/Expander Limiter Digital Delay RTA/SPL/FFT Analyzer with Auto EQ function
Dual 31-band Graphic Equalizers, 31-band Virtual Para-graphic Equalizers and 10-band Parametric
Naturally, the DEQ2496 has a phase-neutral digital graphic EQ. But in addition, we’ve added a function that allows you to change the frequency bandwidths from 1/3, to as tight as 59/3. Or, if you prefer the old-school approach to variable bandwidth, we’ve included 10-bands of parametric filters that can be incrementally fine-tuned all the way down to 1/60 of an octave.
Dynamic EQ (DEQ) automatically raises or lowers a defined frequency range based on volume level. It’s literally a combination of an equalizer (with frequency center and bandwidth controls) and a dynamics processor (with Attack, Release, Threshold and Ratio parameters). DEQ opens up a world of both creative mastering and PA problem solving possibilities. We’ve given you total control with multiple filter types including bandpass mode. And of course you can store DEQ settings for recall at any time manually or via MIDI.
While usually considered a mastering technique, the ability to widen the stereo image can be useful in live sound work, too. The DEQ2496 Width processor provides control over Stereo Width (how clearly the two sides of the stereo image are separated from each other), Asymmetry (relative volume of left/right stereo signal), Rotation (panning of stereo + mono in the stereo image) and a multipart Shuffle function than can generate an additional low-frequency stereo width effect.
Compressor/Expander and Limiter
The DEQ2496 has a comprehensive set of dynamics processing tools that can be used as two independent channels or stereo linked. Everything you’d find on a dedicated compressor/expander is here, including variable ratios from 1:1.1 – 1:100, Attack times of 0 – 200 ms, 0 – 3 dB variable knee and 20 ms – 4 s Release times, all adjustable via a coarse/fine adjustment scale. The built-in separate Limiter features Threshold, Hold and Release functions.
Superb Audio, Sound Value
When you want to bring out the very best from your sound system or your performance, in the studio or at your next live gig – put your trust in the ULTRAGRAPH PRO FBQ3102HD. We dare you to compare it to the competition. Once you do, you’ll choose Behringer again and again for both audio quality and value. Test drive the high-definition FBQ3102HD today at your authorized Behringer dealer.
Ultra-high resolution 24-bit/96 kHz mastering processor featuring 32/40-bit floating-point DSP technology
Audiophile 24-bit/96 kHz A/D- and D/A converters offering 113 dB dynamic range
4 concurrently selectable EQ modules (31-band graphic EQ, 10-band parametric EQ, Feedback Destroyer plus 3 Dynamic EQs per stereo channel)
Ultra-high resolution 61-band real-time FFT analyzer with additional auto EQ function for room and loudspeaker equalization
Unique VPQ (Virtual Paragraphic EQ) option allows parametric control of graphic EQs
State-of-the-art compressor/expander with peak limiter per stereo channel, additional stereo imager and stereo delay for delay line applications
Multi-functional level meters (peak/RMS, VU and SPL meter with dBA/dBC weighting via RTA/Mic input)
64 user memories for complete setups and/or individual module configurations
Separate mic/line input with phantom power for RTA and Auto-EQ applications
Balanced inputs and servo-balanced outputs with gold-plated XLR connectors, stereo aux output, AES/EBU and S/PDIF inputs and outputs (XLR and optical)
Professional Wordclock input and MIDI connections for full remote control, preset dumps and system updates
Open architecture allowing future software updates via MIDI
“Planet Earth” switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy saving
