FOCUSRITE ISA 828 เครื่องเปลี่ยนแปลงสัญญาณไมค์ 8 ชาแนล

Name: FOCUSRITE ISA 828 เครื่องเปลี่ยนแปลงสัญญาณไมค์ 8 ชาแนล
Brand: FOCUSRITE
SKU: FOCUSRITE ISA 828
Availability: InStock

฿129,000 (รวม VAT 7% แล้ว)

สอบถาม สั่งซื้อ LINE @SoundDD.Shop 02-435-8998

เงื่อนไขและข้อตกลง

เช็ค Stock สินค้ากับเจ้าหน้าที่ ก่อนสั่งซื้อทุกครั้ง
รับสินค้าภายใน 3 - 7 วัน ( ขึ้นอยู่กับที่อยู่จัดส่ง )
สงวนสิทธิ์การเปลี่ยนแปลงข้อมูล ราคา โดยไม่แจ้งให้ทราบล่วงหน้า
สงวนสิทธิ์การรับผิดชอบเนื่องจากการพิมพ์ผิดพลาดต่างๆ

สินค้ารับประกัน
จากศูนย์ชั้นนำ

แบรนด์แท้ 100%
แบรนด์ชั้นนำ

ส่งฟรี!
ตามเงื่อนไข

รายละเอียดเพิ่มเติม
ข้อมูลเพิ่มเติม

FOCUSRITE ISA 828 Eight Channel Mic Pre And Optional A-D

FOCUSRITE ISA 828 เครื่องเปลี่ยนแปลงสัญญาณไมค์ 8 ชาแนล ISA 828 ปรีแอมป์ ไมค์ จากแบรนด์ FOCUSRITE

ISA 828 incorporates eight of Focusrite’s renowned mic pres in a simple-to-operate 2U enclosure, placing eight mic preamps, instrument inputs and line ins at your fingertips. The original Focusrite mic pre was designed to suit the microphones of the time; today’s model makes one small change, adding three additional input impedances to the classic ISA 110 setting, allowing you to match any microphone, old or new, and access a wide range of sounds, from the character and warmth of a vintage mic to the clear transparency of a modern design.

Each mic pre has the option of mic, line or the front-panel instrument input, with variable input impedance to ensure you are getting the best performance from the source. Up to 60dB of gain is available on the four-position rotary and gain range switches, with a further +20dB of continuously variable trim, meaning a huge 80dB of gain is available should it be required. The high-pass filter features variable cut-off frequency between 16 and 420Hz. An array of 6-segment LED meters show peak signal level for the four mic pres, in addition to the four direct inputs to the optional A-D card. Switchable rear-panel insert points allow the use of inline processors such as compression.

คุณสมบัติ

Classic ISA mic preamp design featuring Lundahl LL1538 input transformer
Front-panel instrument inputs to first four channels
Line inputs with dedicated input connectors and front-panel switch
Switchable input impedance including classic ISA 110 setting
High-pass filters
Switchable insert points when used with A-D card
Per-channel six-segment LED peak-level meters
Optional A-D card with up to 192kHz, 24-bit sampling via ADAT or AES3

สเปค

MIC INPUTS
Gain Range (Mic)	0 dB to 60 dB in 10 dB steps
Input Impedance (Mic)	Variable, 600O, 1k4O, 2k4O, 6k8O
Noise At Main Output With Gain At Unity (0 DB) (Mic)	-97 dBu measured with a 22 Hz / 22 kHz bandpass filter
Signal To Noise Ratio Relative To Max Headroom (9dBu) (Mic)	106 dB
THD At Medium Gain (30dB) (Mic)	0.0008 measured with a 1 kHz -20 dBu input signal and with a 22 Hz / 22 kHz bandpass filter
Frequency Response At Minimum Gain (0 DB) (Mic)	-0.5 dB down at 10 Hz and –3 dB down at 110kHz
Frequency Response At Maximum Gain (60 DB) (Mic)	–3 dB down at 16 Hz and –3 dB down 85 kHz
CMRR (Mic)	91.8 dB (Channel 1, 1 kHz, maxiumum gain)
LINE INPUTS
Input Impedance (Line)	10 kO from 10 Hz to 200 kHz
Gain Range (Line)	-20 dB to 10 dB in 10 dB steps
Noise At Main Output With Gain At Unity (0 DB) (Line)	-96 dBu measured with a 22 Hz / 22 kHz bandpass filter
Signal To Noise Ratio Relative To Max (Line)	120 dB
Signal To Noise Ratio Relative To 0dBFS( 22dBu) (Line)	118dB
THD At Unity Gain (0dB) (Line)	0.001 measured with a 0 dBu input signal and with a 22 Hz / 22 kHz bandpass filter
Frequency Response At Unity Gain (0dB) (Line)	0.3 dB down at 10 Hz and –3 dB down at 122 kHz
INSTRUMENT INPUTS
Gain Range (Instrument)	10 dB to 40 dB continuously variable
Input Impedance (Instrument)	1 MO or 300 kO
Noise At Minimum Gain ( 10 DB) (Instrument)	-90 dBu measured with a 22 Hz / 22 kHz bandpass filter
Noise At Maximum Gain ( 40 DB) (Instrument)	-62 dBu measured with a 22 Hz / 22 kHz bandpass filter
THD At Minimum Gain ( 10 DB) (Instrument)	0.002 measured with a 10 dBu input signal and with a 22 Hz / 22 kHz bandpass filter
Frequency Response At 10 DB Gain With -10 DB Input (Instrument)	10 Hz – 200 kHz /- 0.6 dB
Frequency Response At 40 DB Gain With -40 DB Input (Instrument)	-2.5 dB down at 10 Hz and 0 dB at 200 kHz
Roll Off	18 dB per octave 3 pole filter
Frequency (Instrument)	Fixed 75Hz measured at the 3dB down point
WEIGHT AND DIMENSIONS
Weight	8.84 kg (19.5 lbs)
Dimensions (W X H X D)	484mm (W) x 85mm (H) x 305mm (D) (350mm depth with heat sink)
