เครื่องผสมสัญญาณเสียง ITC T-2S01 2 channel mixer of 10 inputs 19 นิ้ว Microphone Pre-amplifier จากแบรนด์ ITC
ITC T-2S01
2 Channel Phono and Microphone Pre-amplifier Stereo
- 2 channel mixer of 10 inputs
- Remote paging console T-319 as mic 1 with highest input priority
- Mic 2-4 with VOX selector over inputs 5-10 and phantom power
- All the 10 inputs with mic, line and high pass filtering selector
- Inputs 7-10 either by XLR mic inputs or by dual RCA line inputs
- Dual channel XLR line outputs
- All inputs include inputs1-10, MIC (remote paging console T-319), chime could be selected to have channel1, channel 2 and channel 1+2 outputs.
- Built-in 2/4 tone pre-set chime, remote chime trigger and local trigger on front panel
- Volume controls are provided over chime, MIC1, inputs 2-10, channel 1 and channel 2 masters. Bass and treble tone control are provided for both channel 1 and channel 2.
- Indicators for input 1-10, power and 2 channel level meters
- AC 110 or 230V and DC 24V operation
ITC T-2S01
Input Sensitivity/Impedance
- MIC/ Line
- ±2.45mV/5KΩ balanced, ±245mV/5KΩ balanced
- Line RCA In
- 500mV/5KΩ unbalanced
Output Level/Impedance
- Master 1, 2
- +4dBu/200Ω balance
- REC
- 0dBu/10KΩ unbalanced
Frequency Response
- Less Than
- -1dB(20Hz~20KHz)
S/N Ratio
- MIC
- More than 60dB
- Line
- More than 75dB
THD
- MIC
- Less than 0.05%
- Line
- More than 0.03%
Cross-talk
- MIC
- More than 60dB
- Line
- More than 75dB
- Power Consumption Power
- 13W
- Power Supply
- ~110V/60Hz or ~230V/50Hz & DC 24V
- Dimensions
- 484x295x44mm
