เครื่องตั้งเวลาและควบคุมสัญญาณเสียง ITC T-6232 เลือกได้ 10 โซน T-6232 10 Zone Weekly Timer จากแบรนด์ ITC
ITC T-6232 10 Zone Weekly Timer with Mp3 System Introduction
คุณสมบัติ
- Built-in weekly timer, monitor, 10 zone speaker selector, 6 channel power sequencer and Mp3 player
- Expandable from 10 zones to 160 zones
- Single Scheduled background music + 160 zone paging + multi voice alarm system
- Single scheduled background music from T-6232 weekly timer’s built-in MP3 player
- 3 modes of voice alarm: all zones, separate zone and neighboring zones voice alarm
- Remote paging console up to 16 units
- 5 amp inputs divided into 10 zones speaker output
- Timely broadcast up to 99 program sources
- Broadcast modes: random, repeat and circle
- 4 regular programs and 1 spare program for emergency/particular circumstance
- Functional swift key for internal MP3 player priority manual broadcast
- Zone1-10 selector, all zone selector, music/paging swtich, MP3 swift button, swift program button, power control channel 1-4 buttons, up/down/left/right/ok buttons
- External power control, external monitor, speaker fault detection and amplifier fault changeover all are optional could be added
- Power handling 5000W over each 10 zones
- System communication is through CAT 5 cable
- The system communication distance up to 1kms
- Memory function even in case of power off
สเปค
Model |
T-6232 |
| Power Output | ~110V/60Hz or ~230V/50Hz4 Program Power+2 AUX powerTotal Power 5KW |
| Function Button | Light touch press buttons include4 power switch buttons, 1 MP3 control button, 1 backup program switch,10 zones speaker selector button, all zones button,1 music or paging switch button.4 menu buttons for switch, 1 ok button |
| Indication Method | 192×64 LCD display, English |
| Audio Output | 1KΩ 0.775V Unbalance(6.35 RC)0V(Short Circuit) Industrial Standard |
| Voltage Input and Output of Alarm | Integrated Terminal Block0V(Short Circuit) Industrial Standard |
| Voltage Output for Power Control | Integrated Terminal BlockCHA CHB CHC CHD CHECHA1-A2 CHB1-B2 CHC1-C2 CHD1-D2 CHE1-E2 |
| Amplifier Input and Output | 0.5W |
| Monitor Power of Speaker | −∞~0dB |
| Monitor Volume Attenuator | 24 hours(hour-minutes-seconds) weekly |
| Time Mode | Total 5pcs(4 normal programs, 1EMC) |
| Program Quantity | Total 512 Steps, 1 day 200 Steps |
Program Steps |
RS422 |
| Communication Protocols | RJ45 |
| Communication Port | 4800bps |
| Communication Speed | 160 zone(16pcs T-6217 10 zone speaker seletor) |
| MP3 Frequency Response | 20Hz~20KHz/ 1dB |
| Mp3 Store Format | Compatible FAT12, FAT16, FAT32 |
| Power Supply | ~110V/60Hz or ~230V/50Hz |
| Dimensions | 484x303x88mm |
| Weight | 6.8Kg |
