เครื่องปรับแต่งความถี่สัญญาณเสียง ITC TS-231Equalizer จากแบรนด์ ITC
ITC TS-231 Stereo 31 Bands Graphic Equalizer
- Stereo 31 bands equalizer by two channels.
- Rack mount type in 2U height.
- Mono bass output frequency adjustable.
- Each channel with high-pass & low-pass filter switch.
- 12 level input & output indicator.
- Input and output both by three type connectors: phone jack, XLR and phoenix.
ITC TS-231
-
Channels
Two
Bands
(2×31) 1/3-Octave ISO Spacing (From 20Hz to 20 KHz)
Travel
20mm(Positive grounded center detent)
Range
±12dB
Impedance
>20KΩ balanced
Maximum Level
+21dB
Impedance
400Ω Balanced, 200Ω Unbalanced
Maximum Level
+21dBu Balanced, +15dBu Unbalanced
Low Cut Filter
10-240Hz, 12dB/octave
High Cut Filter
3K-40KHz, 12dB/octave
Frequency Response
20-20KHz( ±0.5dB )
10-40KHz(+1/-3dB )
THD & Noise
0.008%
S/N Ratio
96dB
Maximum Power
12W
Universal Line Voltage
~110V/60Hz or ~230V/50Hz
Dimensions
484x156x88mm
