ลำโพงลายน์อาเรย์ MACKIE HDA 12 นิ้ว 2 ทาง 1200 วัตต์ เป็นลำโพงแบบอาเรย์ 2 ทิศทางที่ให้เสียงความละเอียดสูงจากการออกแบบที่มีน้ำหนักเบาและกะทัดรัด Arrayable Powered Loudspeaker จากยี่ห้อ MACKIE
Mackie HDA 1200W 12″ 2-Way Arrayable Powered Loudspeaker
The HDA from Mackie is a 2-way powered arrayable loudspeaker that delivers high-definition audio from a lightweight and compact design. The all-wood birch cabinet houses a 12″ neodymium woofer and a pair of Beyma 1.7″ compression tweeters to provide crisp, natural audio reproduction with a wide frequency response. The speaker has a 110° x 20° constant curvature line array design. It can be configured with other speakers in a number of ways. Up to 4 HDA units can be flown with a pair of HD1801 subwoofers, or you can ground stack up to 3 loudspeakers on a single subwoofer or flybar. You can even pole mount a pair of array speakers on a single subwoofer or on a tripod.
Internal Class-D amplifiers provide a combined peak power of 1200W for an incredibly strong performance with low distortion. The efficient amplifier design results in fast recovery and high SPL levels. Built-in HD digital processing includes patented acoustic correction, transducer time alignment and phase correction, and a precision 2-way crossover. All of these elements combine to deliver the best sound experience possible. There are 3 user-selectable voicing modes, letting you adjust the tuning and tone to fit your specific application. Integrated limiting and protection circuitry keep the system operating smoothly and reliably. The speaker offers 4 M10 fly points, plus integrated flyware for easy array setup. An optional flybar and subwoofer flyware kit are available separately.
- 12″ 2-way constant curvature HD array
- 110 x 20 coverage
- Integrated rigging
- Input: 1 x XLR
- Loop output: 1 x XLR
- Three array voicing modes allow easy system configuration
- 1,200W of efficient Class-D Fast Recovery amplification
- LF amp: 500W RMS / 1,000W peak
- HF amp: 100W RMS / 200W peak
- 12″ neodymium woofer with 3″ voice coil by EAW
- Dual Beyma 1.7″ compression drivers
- Patented acoustic correction
- Transducer time alignment and phase correction
- Precision 2-way crossover
- Integrated limiting and protection circuitry
- Integrated fly points or optional flybar support up to 4x HDA and up to 2x HD1801 subwoofers
- Ground stack on HD1801 subwoofer or flybar
- Pole mount up to 2x HDA on HD1801 subwoofer or tripod using dual angle pole cups
- Ultra compact and lightweight (59 lbs.)
- Rugged all-wood cabinet (15mm birch plywood)
- Supported by EAW Resolution prediction software
Active or Passive | Active |
Frequency Response | 52Hz – 20kHz (-10dB) 60Hz – 18kHz (-3dB) |
Amplifier | LF: Class-D, 500W RMS, 1000W Peak HF: Class-D, 100W RMS, 200W Peak |
Coverage | 110° Horizontal x 20° Vertical |
Maximum Sound Pressure Level (SPL) | 124dB Measured 131dB Calculated |
Total Harmonic Distortion (THD) | < 0.03% |
Input Impedance | 11 kOhms |
Crossover | 1.5kHz |
Low Frequency Driver | 12″ (305mm) Paper Diaphragm Woofer with Neodymium Magnet and 3″ Voice Coil |
High Frequency Driver | 2 x 1.7″ (43mm) Beyma Mylar Tweeters with Neodymium Magnets |
Enclosure Material | 15mm Birch Plywood with Black Paint Finish, Powder-Coated Steel Grille, and 2 Integrated Handles |
Connectors | 1 x XLR Input 1 x XLR Parallel Output 1 x Locking Neutrik PowerCon A AC Mains Connector 1 x Locking Neutrik PowerCon B AC Loop Connector |
Mounting | 1 x Standard Pole Socket 4 x M10 Fly Points 1 x Integrated Flybar |
Power | 100-240VAC, 50/60Hz |
Dimensions (HxWxD) | 14.7 x 24.7 x 15.9″ (373 x 628 x 405mm) |
Weight | 59 lbs (26.7kg) |
Packaging Info | |
---|---|
Package Weight | 69.0 lb |
Box Dimensions (LxWxH) | 27.0 x 21.0 x 20.0″ |
