ตู้ลำโพง PRESONUS ULT18 18 นิ้ว 2 ทาง 2,000 วัตต์ มีแอมป์ในตัว คลาส D Active Sound-Reinforcement Subwoofer จากยี่ห้อ PRESONUS
PRESONUS ULT18
Active Sound-Reinforcement Subwoofer
Low-end punch you can hear and feel.
Designed to complement any full-range PA loudspeaker and a perfect companion for the PreSonus® ULT12 and ULT15, the ULT18 subwoofer delivers a powerful, clear, and accurate low-end punch. With 2,000 watts (peak) of Class D power and a direct radiating, ported enclosure, it has all the muscle needed for the detailed low-frequency performance audio pros demand. Its custom 18-inch low-frequency transducer with 4-inch voice coil provides 7 mm of driver travel before over-excursion to push more air and bring more thump.
Extensive controls enable customized performance.
To provide maximum versatility, the PRESONUS ULT18 offers several important user controls. Unlike most subwoofers in this class, the ULT18 features a variable lowpass filter that enables you to accurately dial in the crossover transition between the subwoofer and your full-range system. Two DSP presets provide extended low-frequency performance or a more natural response to suit a variety of applications, and of course you get polarity reverse. A Mono Mode function is also provided to simplify cabling multiple mono subs in a stereo system.
Equally at home in mobile and installed systems.
Like the full-range ULT12 and ULT15 loudspeakers, the ULT18 has a rugged, tour-grade birch enclosure for the distinctive performance characteristics that only wood can offer. A locking IEC power connector, M10 rigging points, integrated castor provisions, and ground-stacking provisions, making it a great choice for a wide variety of mobile and install applications. Two combo XLR and ¼” TRS line-level inputs with level control and throughputs are provided to connect full-range systems or multiple subwoofers in larger systems. As with the ULT12 and ULT15, you can defeat the front power-indicator LED for low-visibility installs.
Designed by WorxAudio.
PRESONUS ULT18 loudspeakers were designed by WorxAudio®, the commercial loudspeaker division of PRESONUS ULT18. Headquartered in Greensboro, North Carolina, WorxAudio has been at the forefront of loudspeaker development for the pro touring and contractor markets for over 30 years. WorxAudio continues to embrace the latest technology, delivering innovative products and installation designs for professional clients, and their products can be found in prestigious facilities worldwide. So you can rely on ULT loudspeakers to deliver the top-quality professional performance and features that touring engineers and systems integrators need.
Now hear this.
With flexible connectivity; a rugged, tour-grade enclosure; and generous Class D power, the ULT18 delivers the versatility and punch expected from today’s professional sound systems and is an excellent solution for permanent installations. Yet it’s also portable, making it a top choice for tours and other mobile use. Although designed to complement ULT-series full-range loudspeakers, the ULT18 is also an excellent companion for third-party loudspeakers. Most important, it sounds great, delivering outstanding low-end clarity and natural music reproduction. Hear ULT-series loudspeakers for yourself at your favorite PreSonus dealer.
Main Components
- 15-inch custom woofer with 2.5-inch voice coil
- WorxAudio®-designed waveguide Pivot X110 horn for precise coverage
- Ultra-wide 110˚ horizontal dispersion
- Tight 50˚ vertical dispersion for longer throw
- 1,300W Class D power (150x500W continuous)
- XMAX preamp
- Onboard mixer with two combo XLR and ¼” inputs
- Direct line-input channel output
- Single summed balanced output
Controls
- Mic/Line Level
- Line/Level
- 3 operation mode presets
- FOH – normal live front of house
- DJ – Music playback
- Mon — stage wedge floor monitor
- HPF On/Off
- Front LED On/Off
Convenience Features
- Multi-angle enclosure for mains or monitor wedge application
- Defeatable front-panel LED
- Rugged, texture-painted eucalyptus plywood enclosures
- Tour-grade 16 gauge steel grille
- Comfortable ergonomic handles
- 35 mm pole sockets with 6˚ downward tilt
- Integrated M10 rigging points for suspended horizontal and vertical installation
- Locking IEC connection
Acoustic Performance
| Configuration | 2-way biamped |
| Frequency Response (-3 dB) | 52 Hz – 18 kHz |
| Frequency Response (-10 dB) | 47 Hz – 20 kHz |
| Nominal Coverage (-6 dB) | 110° x 50° |
| Maximum Peak SPL | 136 dB |
| Crossover Frequency | 1.6 kHz |
Transducer
| LF Transducer | 1×15″ Ferrite |
| Voice Coil Diameter | 2.5” |
| HF Transducer | 1.75″ compression drive |
Amplifier
| Type | Class D |
| Total Power Output | 1,300W Peak (650 RMS) |
| LF Power | 1,000W Peak (500W RMS) |
| HF Power | 300W Peak (150W RMS) |
| Cooling | Free air convection |
| Rated THD | <0.05% (20 Hz – 20 kHz) |
| Dynamic Range | 119 dB (A-weighted) |
| Bandwidth | 20 Hz – 20 kHz |
Connections and Controls
| Input Channels | 1 mic/line, 1 line |
| Input Connector Types | 2 combo |
| Mic Input Impedance | 1 kΩ |
| Line Input Impedance | 10 kΩ |
| Maximum Input | +22 dBu |
| Output Connector | 2 XLR (M): Mix out, Direct out |
| Control | Mic/Line Level Line/Level Preset Select HPF On/Off Front LED On/Off |
| Indicators | DSP Preset, HPF On/Off, Front LED On/Off, Signal, Clip, Thermal |
DSP
| Presets | FOH, MON, DJ |
| Polarity | – |
| HPF | 100 Hz, 4th-order Linkwitz-Riley |
| Bit Depth | 24-bit |
| Sample Rate | 96 kHz |
Enclosure
| Material | Eucalyptus Plywood |
| Finish | Chemline™ polyurethane |
| Grille | Powder-coated steel |
| Dimensions (HxDxW) | 28.5” x 17.25” x 16” (724 mm x 438 mm x 406 mm) |
| Unit Weight | 59 lbs. (26.8 kg) |
| Handles | 3 (Top and Side) |
| Monitor Angle | 30° |
Safety
| Amplifier Protection | Over-current, DC, over/under-voltage, over-temperature, high frequency |
| Transducer Protection | limiter |
Power
| AC Power Input | 100-230V~, 50-60 Hz |
| AC Power Consumption (1/8 Power) | 150W |
Suspension Mounting
| Rigging Points | 12 M10 |
| Mounting | 35 mm, 2-position |
