Configuration |
Biamp or Triamp mode |
Transducers
High Frequency
Low Frequency |
1.4-inch exit, 3-inch titanium diaphragm, neodymium magnet assembly
2 × 400 W, 16 ohm 10-inch woofer, 3-inch voice coil, ceramic magnet assembly |
Frequency Response (±3 dB)
Frequency Response (-10 dB) |
55 Hz to 18 kHz (with recommended DSP processing)
48 Hz to 20 kHz (with recommended DSP processing) |
Nominal Impedance |
HF: 16 ohms
LF biamp mode: 8 ohms
LF triamp mode: 16 ohms (× 2) |
Continuous Power Capacity |
HF: 80 W (2 hours, AES1984-2 method, 1 to 10 kHz)
LF biamp mode: 600 W (2 hours, AES1984-2 method, 80 to 800 Hz)
LF triamp mode: 400 W (×2) (2 hours, AES1984-2 method, 80 to 800 Hz) |
Max Recommended Power |
HF: 300 W @ 16Ω
LF bi-amp mode: 1400 W @ 8Ω
LF tri-amp mode: 700 W @ 16Ω (x 2) |
Sensitivity (1 W at 1 m) |
HF: 107.5 dB (single cabinet measured in free space.)
LF: 98 dB (single cabinet measured in free space. LF drivers connected in parallel) |
Maximum Output (SPL at 1 m)
Continuous:
Peak: |
HF: 127 dB / LF: 127 dB
HF: 133 dB / LF: 133 dB |
Maximum Output (dB SPL at 1 m)
Continuous / Peak |
HF: 126 dB / 132 dB
LF: 122 dB / 128 dB |
Nominal Coverage |
Horizontal: 140°
Vertical: Dependent on number of elements used |
Enclosure |
Cabinet Type |
Ported, trapezoidal |
Material |
Baltic birch plywood |
Finish |
Available in standard black finish |
Grille |
Perforated, formed powder coated steel |
Connectors |
2 × Neutrik Speakon® NL8 in parallel |
Pinout |
Pins |
Bi-amp |
Tri-amp |
1+/1- |
LF |
MF |
2+/2- |
NC |
LF |
3+/3- |
NC |
NC |
4+/4- |
HF |
HF |
|
Attachment Points |
Integral, adjustable rigging system, vertical splay adjustable in 1° increments from 2 ° to 10° and 0° |
Dimensions (H×W×D) |
273 × 698.5 × 514.3 mm
10.75 × 27.5 × 20.25 in |
Carton Dimensions (H×W×D) |
280 × 711 × 533 mm
11 × 28 × 21 in |
Net Weight |
37.7 kg / 83 lb |
Shipping Weight |
42.6 kg / 93.9 lb |
Accessories Available |
AF2102-LA |
