RCF F 6X มิกเซอร์ อนาล็อก 6 ชาแนล

• 2 Mic/Line inputs
• 2 Stereo line inputs
• One Aux/FX (post)
• Balanced main output audio path from input to output
• PRO DSP FX onboard with 16 presets
• Sturdy metal chassis
• External universal power supply
• Designed and engineered in Italy

RCF’s next generation F Series mixers builds on the rich analog legacy found in the professional E Series, featuring high quality sound in four formats from 6 to 16 channels. A powerful tool for the musician and the sound enthusiast, entirely conceived and designed by the RCF R&D team. Housed in a sturdy metal chassis, each mixer features a full balanced audio path from input to output and the unique PRO DSP FX: 16 professional effects such as Reverbs (Halls, Rooms, Plates, Spring), Delays (Mono, Stereo and Multitap), Chorus, Flangers and Echoes. The models F-10XR, F-12XR, and F-16XR, include an USB audio interface, for stereo recording on computer-based DAW and 2-channel playback.

Electrical specifications

• FREQUENCY RESPONSE : 20 Hz ÷ 20 kHz
• THD+N, 20DB GAIN, 0DBU OUT (% A-WEIGHTED) : <0.02
• POWER SUPPLY : Internal
• VOLTAGE REQUIREMENTS : 100 V – 240 V
• POWER CONSUMPTION (W) : 12 W

Inputs

• GAIN RANGE : 0 dB ÷ -50 dB
• GAIN SELECTION : 20 dB ÷ -30 dB
• MIC INPUTS IMPEDANCE (KOHM ): 14 kohm
• LINE : 2
• LINE INPUT IMPEDANCE (KOHM) : 21 kohm
• LOW CUT : 80 Hz
• MIC : 2
• PHANTOM POWER +48V : Yes
• STEREO LINE : 2
• STEREO LINE GAIN SELECTION : 20 dB ÷ -30 dB
• STEREO LINE INPUT IMPEDANCE : 15 kohm

Outputs

• MAIN MIX : 1
• FX SEND : 1
• AUX OUTPUT : 1
• PHONES : 1

Outputs specifications

• MAIN OUT LEVEL (DBU) : 28 dBu
• AUX OUT LEVEL (DBU) : 28 dBu
• PHONES OUT IMPEDANCE (OHM) : 150 ohm

EQ

• INPUT CHANNELS EQ : 2 Shelving 1
• DESCRIPTION : High:+/-15 dB @ 10 kHz Shelving, Mid:+/-15 dB @ 1,250 kHz, Bell Low:+/-15 dB @ 100 Hz Shelving.

Auxiliary sends

• FX POST : 1

Internal Effects

• SEND EFFECTS : 1

Other features

• FOOTSWITCH : Yes

Standard compliance

• CE MARKING : Yes

Physical specifications

• CABINET/CASE MATERIAL : Metal
• COLOR : Black

Size

• DEPTH : 255 mm / 10.04 inches
• HEIGHT : 79 mm / 3.11 inches
• WEIGHT : 1.8 kg / 3.97 lbs
• WIDTH : 210 mm / 8.27 inches

Shipping informations

• PACKAGE DEPTH : 260 mm / 10.24 inches
• PACKAGE HEIGHT : 122 mm / 4.8 inches
• PACKAGE WEIGHT : 2.75 kg / 6.06 lbs
• PACKAGE WIDTH : 378 mm / 14.88 inches
