สเปค

• Mic Inputs: 12 (8x XLR / 4x Combo XLR)
• Stereo Inputs: 2
• Master Output: 2 (Left/Right balanced XLR)
• Smart Outputs: 6 (assignable balanced XLR)
• Internal busses: 16
• Stage monitor: 1 TRS Jack output
• Headphone: 1 TRS Jack output
• Screen: 7″ high definition touch screen
• Operation system: Android system
• Remote system: IOS app for Ipad
• Network: Yes, via WiFi module
• Sample Frequency: 48 KHz
• AD/DA: 192 KHz, 24-bit
• DSP: 40 bit float point, SHARC processor
• Effects: up to 8 assignable effect modules
• AES/EBU: Output XLR
• S/PDIF: Input / Output (RCA Phono)
• USB Interface: 2 for playback/recording, scene/setting storage and system updates
• Power Supply: 90-240V ~ 50/60Hz IEC power supply
