ลำโพงติดผนัง TANNOY iW 6DS-WH 6 นิ้ว 2 ทาง 280 วัตต์ In-Wall Loudspeaker ขนาดกะทัดรัดสำหรับการฟังเพลงแบบหลายโซน จากยี่ห้อ TANNOY
TANNOY iW 6DS-WH
2 Way 6″ In-Wall Loudspeaker
iW 62S-WH
Designed to excel in a wide variety of sound reinforcement applications, the iW 62S-WH is a compact 640-Watt wall mount subwoofer that provides inspiring acoustic performance with exceptional low frequency punch and power. The iW 62S-WH is ideally suited for paging systems, boardrooms, offices, business music systems, reception rooms, houses of worship, retail outlets, shopping malls and bars.
Superb Performance
iW 62S-WH’s design comprises dual 150 mm (6.00″) bass drivers mounted in an enclosure that is robust enough for commercial applications. This configuration handles up to 640 Watts to deliver exceptional transient response with highly accurate time and phase coherence, all in a compact and highly efficient system that is well-suited to a wide range of amplifier options – including entry level amplifiers.
Attractive & Easy to Install
The semi matt white, weather resistant grille and enclosure can be painted to match any décor, and features an innovative self-aligning clamping system for easy installation into standard stud partition walls.
- 2 way compact wall mount loudspeaker for multi-zone music and AV systems
- 25 mm titanium diaphragm high frequency unit delivers exceptional clarity and articulation throughout the high frequency range
- 6? bass driver provides exceptional low frequency performance
- 70 Watts continuous, 280 Watts peak power handling delivers exceptional dynamics and realism
- Highly efficient 89 dB/Watt sensitivity
- WideBand* tweeter technology to enhance reproduction of wide band digital audio formats
- Robust construction and performance allows use within commercial environments
- Ideal for paging systems, boardrooms, offices, business music systems, reception rooms, houses of worship, retail outlets, shopping malls and bars
- Weather resistant steel mesh grille to protect driver
- Semi matt white finish fits unobtrusively in any environment
- Both baffle and grille may be painted to match d?cor
- Innovative self-aligning clamping system for easy installation into standard stud partition wall
- Dynamic high frequency protection
- Tannoy – Over 90 years of British sound heritage and innovation
- Designed and engineered in the U.K.
Performance
| System Type | In-wall loudspeaker |
| Frequency Response (1) | 75Hz – 51kHz ( /-3dB) |
| Low Frequency Alignment (2) | 36Hz (-6dB) |
| Recommended Amplifier Power | 20 – 180W @ 8 Ohms |
| Power Handling (3) | Average: 90W Programme: 180W Peak: 360W |
| Sensitivity 2.38 Volts @ 1 metre (1) | Anechoic: 91dB Half space: 94dB |
| Maximum SPL @ 1 metre (4) | Average: 110dB Peak: 116dB |
| Impedance | 8 Ohms |
Drive Units
| Dispersion | 90 degrees |
| Driver Complement | Supertweeter™: 25mm (1.00”) titanium dome Dual Concentric™: 25mm (1.00”) titanium dome Bass driver: 165mm (6.50”) |
Crossover
| Frequency | 1.8kHz, 16kHz |
| Type | Passive |
Optional THP 60 Transformer
| Maximum SPL (4) | 107dB |
| Wattage Tap Selections | 60, 30, 15, 7.5 Watts |
Construction
| Finish | White – paintable |
| Connectors | Gold plated spring terminals |
| Dimensions (H x W) | Front baffle: 320 x 209mm (12.60 x 8.23”) Maximum wall thickness: 25mm (1.00”) |
| Cut-out Dimensions (H x W) | 271.50 x 168.50 (10.68 x 6.63″) |
| Rec. in-wall Mounting Volume | 20 litres (0.7 cu.ft.) |
| Mounting Depth | 98.9mm (3.89”) |
| Weight (each) | 3kg (6lbs 6oz) |
| Accessories | Pre-installation ring Back can Back can with 60W transformer |
