WHARFEDALE-PRO LMX-204 Audio Processors
WHARFEDALE-PRO LMX-204 Stereo Two-Way Crossover เครื่องตัดแบ่งความถี่เสียงลำโพง LMX-204 Crossover จากแบรนด์ WHARFEDALE PRO
The crossover frequency is sweepable from 60Hz to 1KHz providing an ideal frequency split suitable for feeding subs and full range units with discrete bandwidths right out of the box.
If you wish to use the XO-204 to split the programme material in a manner that is suitable to feed the mid and high drivers in a bi-amp compatible full range unit the X10 switch conveniently raises the crossover frequency to allow for this.
Emphasis has been placed on the safety of your rig with a switchable 40Hz 12dB/octave HPF to increase headroom and independent switchable soft limiting on each of the bands to protect your amp and speakers.
To help fine tune the setup of your system there are mute switches for each of the bands and also independent polarity switching.
The XO-204 active crossover has independent output level control ranging from -infinity to +6dB, to assist you there are LED output meters and a simple input clip LED.
All inputs and outputs are on balanced TRS jacks and there is the inclusion of a mono summed LF output for using a mono subwoofer in a stereo situation. The XO-204 comes in a 1U 19” rackmount chassis and accepts mains power via an IEC connector.
- OPERATING VOLTAGE : 100VAC 50/60Hz, 120VAC 60Hz,
- POWER CONSUMPTION : 230VAC 50/60Hz
- MAINS CONNECTION : 12W
- CONNECTORS : 1/4″ TRS (pin 2 hot)
- INPUT IMPEDANCE : Balanced 20k ohm, Unbalanced 10k ohm
- MAX INPUT LEVEL : +20dBu balanced or unbalanced
- OUTPUT IMPEDANCE : Balanced 50ohm, Unbalanced 100ohm
- MAX OUTPUT LEVEL : +21dBu
- SUBWOOFER OUTPUT : 1/4″ TRS (pin 2 hot)
- SIGNAL-TO-NOISE : 90 dB
- THD + NOISE : <0.004%
- INTERCHANNEL CROSSTALK : <-80dB, 20Hz to 20kHz
- FREQUENCY RANGE : 60Hz-10kHz
- HUM AND NOISE : -95dB
- FREQUENCY RESPONSE : <10Hz to >40kHz, +2/-3dB
- DIMENSIONS/WEIGHT : IEC receptacle
- DIMENSION : 482x 250 x 46mm
- WEIGHT : 2.92 kg
