System Type |
Active 8” 2-way Bi-Amplified |
Active 8” 2-way Bi-Amplified |
Frequency Response (+/-3 dB) |
65-20 kHz |
65-20 kHz |
Sensitivity @ 1 w / 1 meter |
95 dB |
95 dB |
Maximum SPL (peak @ 1 meter) |
124 dB |
124 dB |
Low Frequency Transducer |
|
|
Size (mm / inches) |
203 mm / 8″ |
203 mm / 8″ |
Coil Size (mm / inches) |
38.86 mm / 1.53″ |
38.86 mm / 1.53″ |
Impedance |
4 Ω |
4 Ω |
High Frequency Transducer |
|
|
Type |
Compression Driver |
Compression Driver |
Coil Size (mm / inches) |
44.5 mm / 1.75” |
44.5 mm / 1.75” |
Exit Size (mm / inches) |
25 mm / 1” |
25 mm / 1” |
Diaphragm Material |
Titanium |
Titanium |
Impedance |
8 Ω |
8 Ω |
High Frequency Coverage (H x V) |
90° x 60° |
90° x 60° |
Amplifiers |
Class D |
Class D |
Low-Frequency Power Amplifier |
150 w Continuous / 300 w Peak |
150 w Continuous / 300 w Peak |
High- Frequency Power Amplifier |
100 w Continuous / 200 w Peak |
100 w Continuous / 200 w Peak |
Electronic Crossover |
|
|
Crossover Frequency |
2.6 kHz |
2.6 kHz |
Controls |
|
|
Equalization |
+/-12 dB Gain for bass and treble |
+/-12 dB Gain for bass and treble |
Amplifier Protection |
|
|
Power On Protection |
Power switch on / off mute |
Power switch on / off mute |
Thermal Protection |
Amplifier shutdown, auto reset |
Amplifier shutdown, auto reset |
Driver, DC and Short Protection |
Yes |
Yes |
Limiter Indicator |
Red LED |
Red LED |
Power Indicator |
Green LED / Blue LED(LOGO) |
Green LED / Blue LED(LOGO) |
Input type |
Balanced / unbalanced |
Balanced/unbalanced/Bluetooth/USB |
Input Connectors |
TRS JACK / FEMALE XLR / RCA |
TRS JACK / FEMALE XLR / RCA / USB |
Input Impedance |
47 KΩ Balanced |
47 KΩ Balanced |
Maximum Input Level |
5 V |
5 V |
Line Input Sensitivity |
-10 dB |
-10 dB |
Mic Input Sensitivity |
-40 dB |
-40 dB |
Line Output Connector |
MALE XLR |
MALE XLR |
AC Power details |
|
|
Power Supply |
SMPS |
SMPS |
AC Power Options |
100 V – 120 V and 220 V – 240 V |
100 V – 120 V and 220 V – 240 V |
Power On Indicator |
LED |
LED |
Rigging / Bracket / Mounting Options |
4 x M8 |
4 x M8 |
|
35 mm Pole-mount with lock screw |
35 mm Pole-mount with lock screw |
|
3 carry handles (one on each side, one on top) |
3 carry handles (one on each side, one on top) |
|
Optional wall-mount bracket (WPB-2) |
Optional wall-mount bracket (WPB-2) |
Enclosure |
|
|
Enclosure Material |
Injection Moulded Polypropylene |
Injection Moulded Polypropylene |
Colour |
black |
black |
Grille |
1.2 mm steel |
1.2 mm steel |
Dimensions (Unpacked)(mm / inches): |
|
|
Height |
421.4 mm / 16.6” |
421.4 mm / 16.6” |
Width – Front |
259 mm / 10.2” |
259 mm / 10.2” |
Width – Rear |
171.9 mm / 6.7″ |
171.9 mm / 6.7″ |
Depth |
263.2 mm / 10.4” |
263.2 mm / 10.4” |
Dimensions (packed)(mm / inches): |
|
|
Height |
470 mm / 18.5” |
470 mm / 18.5” |
Width |
315 mm / 12.4” |
315 mm / 12.4” |
Depth |
307 mm / 12.1” |
307 mm / 12.1” |
Weight |
|
|
Net Weight (kg / lbs) |
8.0 kg / 17.6 lbs |
8.0 kg / 17.6 lbs |
Gross Weight (kg / lbs) |
9.2 kg / 20.24 lbs |
9.2 kg / 20.24 lbs |
