AV Receiver DENON AVC-X6700H 11.2 ชาแนล 205 วัตต์ต่อชาแนล รองรับ 8K, Dolby Atmos, DTS: X, DTS: X Pro, IMAX Enhanced และ Auro-3D จากแบรนด์ DENON
DENON AVC-X6700H
This premium 11.2 channel 8K AV Amplifier with 205W per channel
This premium 11.2 channel 8K AV Amplifier with 205W per channel fully supports Dolby Atmos, DTS:X, DTS:X Pro, IMAX Enhanced and Auro-3D. The AVC-X6700H also supports the latest HDMI specifications such as 8K/60Hz and 4K/120Hz pass-through, VRR, ALLM, Dynamic HDR, HDR10+ and eARC support.
สเปค
Multichannel Surround
- DTS HD Master / DTS:X
/ - DTS:X Pro (Update)
- DTS Neo:X / DTS Neural:X
/ - DTS Virtual:X
- Dolby TrueHD / Dolby Atmos /
- Dolby ProLogic Il / Dolby Surround /
- Dolby Height Virtualization
- Front Wide Speakers: Dolby / DTS /
- Auro 3D 13ch
- IMAX Enhanced
- IMAX Enhanced (Update)
- Multichannel Stereo
- Max Number of Processing (Preamp) Channels 13.2
Sound Enhancements
- Mono Block Power Amp Construction
- Discrete Power Amplifier 11
- 110th Anniversary Audio Tuning
- Iron diecast feet
- Copper plated transformer base
- Premium speaker terminals
- All black interior
- D.D.S.C. HD Digital (32 bit)
- Pure Direct
- High Grade Audio Components
- Gold Plated RCA Terminals
- Clock Jitter Reducer
- Alpha Processing : AL32 Processing Multichannel
- Audyssey : MultEQ XT32
- Audyssey Dynamic EQ / Dynamic Volume /
- Audyssey LFC
- Audyssey APP support
- Speaker Setup Presets 2
- Compressed Audio Restorer
Network
- HEOS Multiroom and Streaming
- Lossy Formats: MP3 / WMA / AAC / /
- Lossless Formats: FLAC / ALAC / WAV / /
- DSD Audio Streaming : up to DSD5.6
- FLAC HD 192/24
- WAV 192/24
- ALAC 192/24
- Gapless Playback (FLAC, WAV, ALAC, DSD)
- AirPlay 2
- Roon Tested
- Internet Radio : TuneIn
- Spotify Connect / Tidal / Deezer / others / / /
- Amazon Prime Music* / Pandora* /
- Compatible with Remote APP for Smart Phones : Android / iOS
- Compatible with Remote APP for Tablets : Android / iOS/Amazon Kindle
- Ethernet Ports
- Wi-Fi
- Bluetooth
- Bluetooth Headphone transmission
HDMI
- HDMI Inputs: Back / Front 7 / 1
- HDCP2.3 support
- HDMI Outputs: Main / Zone : 2 / 1
- HDMI max Resolution (8k / 4k) : 8k/60 – 4k/120
- Video Conversion Analog -> HDMI :
- HDMI to HDMI Scaling : up to 8K 60/50
- HDMI: 8K / 4K / CEC / eARC : / / /
- HDMI: Dolby Vision / HDR 10+ / Dynamic HDR / HLG : / / /
- HDMI: ALLM / QMS / QFT / VRR : / / /
- HDMI pass-though in standby mode :
- DSD Audio Capability :
Multiroom / CI
- HEOS Multiroom integrated
- TV Sound grouping
- Multi-Room Zones 3
- Main room multichanel audio – Zone stereo downmix
- Zone Audio Source: HDMI / Opt, Coax / Network, USB / Analog : (2ch) / (2ch) / /
- Zone Audio Output: Speaker / Preout /
- Zone HDMI Output from HDMI Source
- Webbrowser Setup
- IP Control / RS232 Control / Web Control / App Control / / /
- Remote In / Out /
- DC Trigger Output : 2
Others
- Voice Control – Works with Amazon Alexa :
- Voice Control – Google Assist Apple Siri : /
- Voice Control – Microphone built-in
- Auto Speaker Setup by Microphone : Audyssey MultEQ XT32
- FL Display : 2 lines
- Graphic User Interface – GUI : Advanced
- ISF Certification
- GUI Languages : 9
- Setup Assistant
- Quick Select Plus / Quick Select /
- Firmware Update by Network / USB /
- Variable Cross Over
- Optimized Bass Redirection
- Bass Sync
- ECO Mode
- Auto Power Off
- Sleep Timer
Inputs/Outputs
- Composite In / Out 4 / 2
- Component In / Out 2 / 1
- HDMI In / Out 7+1 / 3
- Multi-room Video Out: Video / HDMI /
- Analogue In / Out 7 / –
- Phono (MM) In
- Digital In: Optical / Coaxial 2 / 2
- Multi-room Out: Analog / Digital 2 / –
- Multichannel Preout (13.2)
- Subwoofer Out 2 (independent)
- 7.1 Multichannel Input
- Speaker Terminal: Gold Plated Screw / Regular Screw /
- Number of Speaker Terminals 13
- Speaker A / B : assignable
- Bi-amp Drive : assignable
- Multi-Room Speaker Terminal : assignable
- Front Inputs: Audio / Composite / Digital (Opt) / HDMI / USB / / / /
- USB Audio / Made for iPod / Made for iPhone / AirPlay / AirPlay
- DAB / DAB+ tuner
- FM Tuner with RDS
Specifications
- Number of Poweramps : 1
- Power Output (8 ohm, 20 Hz – 20 kHz, 0.08% 2ch Drive) :
- Power Output (8 ohm, 20 Hz – 20 kHz, 0.05% 2ch Drive) : 140 W
- Power Output (6 ohm, 1 kHz, 0.7% 2ch Drive) : 175 W
- Power Output (6 ohm, 1 kHz, 1% 1ch Drive) : 205 W
General
- Available Colours: Black / Premium Silver /
- Metal Front Panel
- System Remote Control RC-1240
- Pre-programmed / Learnable / LCD Display / /
- Power Consumption in W 750
- Power Consumption No-Sound (ECO On / Off) in W 65 W / 110 W
- Standby Consumption in W : 0.1
- CEC Потребляемая мощность в режиме ожидания (Вт) : 0.5
- Network Control On Consumption in W: 3.7
- Maximum Dimensions
Antenna:Horizontal: (W x D x H) in mm 434 x 389 x 167
Antenna:Vertical: (W x D x H) in mm ( 434 x 389 x 235 )
No Antenna: (W x D x H) in mm 【 434 x 379 x 167 】 - Weight in kg : 14.8
- Carton Maximum Dimensions (W x D x H) in mm : 531 x 464 x 302
- Carton Weight (inc. product) in kg : 17.4
