ไมล์เลือก Zone ประกาศ ITC T-328 ต้องใช้งานร่วมกับเครื่องผสมสัญญาณเสียง รุ่น T-6245 เท่านั้น Station Microphone จากแบรนด์ ITC
ITC T-328
Paging Station Microphone
คุณสมบัติ
Zone selection
- Push the switch for one zone or all zone and the zone led turn on.
Announcement
- After selecting the zone where to make the announcement, then keep pushing the talk button till the led turn on, the internal chime will be heard, after that, the user could proceed with the announcement. If the zone selected is already taken by another connected paging console, the talk led starts blinking which means line is busy.
Pre-recorded message 3 remote trigger
- After selecting the zones, push the alarm button to activate the pre-recorded voice message 3 broadcasting. Based on the setting of continuous and once play modes from T-6245, the accordingly activity will be taken.
Priority
- The remote paging announcement with priority over mic1, chime and pre recorded message broadcasting.
Pre-recorded messages
- Three different voice messages could be recorded and stored in the mixer, while each message’s broadcasting time max is 3 minutes.
สเปค
|
Model |
T-328 |
|
MIRCOPHONE INPUT |
|
|
Sensitivity |
±5 mV/600Ω |
|
S/N Ratio |
>68dB |
|
Frequency Response |
100Hz~17KHz(+1, -3dB) |
|
Phantom Power |
+12V |
|
CONTROL |
|
|
Bass |
±12dB at 100Hz |
|
Treble |
±12dB at 10KHz |
|
Chime |
2 tone active for contact free in priority and BGM |
|
Normal Distortion |
>0.1% |
|
OPERATING CONDITION |
|
|
Power Supply |
DC 24V |
|
Dimensions |
220×142.7×51.5 mm |
|
Weight |
1.5Kg |
|
Max number of paging console |
6 |
