MAGNET CYGNUS ปรีแอมป์ เครื่องขยายเสียง คลาส A CYGNUS ปรีแอมป์ จากแบรนด์ MAGNET
MAGNET CYGNUS
A Truly Balanced Luxurious Listening Experience
True Balanced Circuitry to Compliment our Power Amplifiers for the Highest Possible Performance
- Balanced inputs and outputs for minimum noise
- Wireless Remote
- Tracking” regulated power supplies for maximum detail
- Direct-coupled signal paths employing Richard’s “Servo-Control” Technology
Advanced ”Class A” Circuitry
The Cygnus advanced circuitry runs in pure ”Class A” for uncompromising performance. Bi-polar and FET field effect transistors are used in a folded cascade configuration for linear, low noise operation.
Finally, The Cygnus is flexibility that is provided for with 3RCA and 3 Balanced XLR input pairs and full inferred remote controlled functions over volume, mute, input selection and turn ON-OFF.
สเปค
| Frequency response | 20Hz-50kHz +/- 0.5dB |
| ฺBandwidth | 0.5Hz-300kHz (-3dB) |
| Total harmonic distortion THD+Noise | Better Than 0.003% @ 1.0Vrms OUTPUT |
| Signal to noise Ratio | Better Than -85dB @ 20kHz |
| Channel Seperation | Better Than -94dB @ 1kHz or -91dB @ 20kHz |
| Input Impedance | 1Mega Ohm Unbalanced / 2Mega Ohm Balanced |
| Input Sensitivity | 20mV @ 1.0Vrms OUTPUT |
| Maximun signal voltage output | 9.0 Vrms |
| Remote Trigger Input | 3-30V AC/DC 15mA +/- 5mA |
| Remote Trigger Output | 12 Vdc 100mA |
