สเปค

• Dimensions

XSW-D XLR FEMALE TX: approx. 102 x 24 x 28 mm

XSW-D MINI JACK TX: approx. 86 x 24 x 28 mm

XSW-D INSTRUMENT TX: approx. 122 x 24 x 28 mm

XSW-D XLR MALE RX: approx. 109 x 24 x 28 mm

XSW-D MINI JACK RX: approx. 86 x 24 x 28 mm

XSW-D INSTRUMENT RX: approx. 122 x 24 x 28 mm

XSW-D PEDALBOARD RX: approx. 130 x 82 x 51 mm

• THD, total harmonic distortion

< 0.1 %

• Charging time

typ. 3 h

• Audio output

max. 12 dBu

• Operating temperature

-10 °C to +55 °C (14 °F to 131 °F)

• Signal-to-noise ratio

≥ 106 dB

• Operating time

up to 5 h

• Modulation

GFSK with TDMA

• Battery Specification

Li-Ion

• Capacity

850 mAh

• Codecs

aptX® Live

• Frequency range

2,400 – 2,483.5MHz

• Input voltage

typ. 5.0 V

• Transmission power

max. 10 mW

• Voltage

3.7 V

• Operating relative humidity

95 % (non-condensing)

• Latency

< 4 ms

• Temperature Range

0 °C – 60 °C (32 °F – 140 °F)

• Audio frequency response

3.5 mm Jack/XLR: 80 – 18,000 Hz

6.3 mm Jack: 10 – 18,000 Hz
