ชุดไมค์ลอย แบบมือถือเดี่ยว SENNHEISER XSW2-835 ย่าน UHF XSW2-835 ไมค์ลอย จากแบรนด์ SENNHEISER
SENNHEISER XSW2-835
Wireless Microphone System
Raise your voice. High flexibility for those willing to go a step further. XS WIRELESS 2 grows with your demands by offering an intuitive LCD display for more manual options and 12 compatible channels in a stable UHF band, withstanding tougher live stage conditions. The XS WIRELESS 2 VOCAL SET is an easy to use all-in-one wireless system for singers and presenters featuring Sennheiser’s renowned evolution microphone capsule e835 (superior dynamic, cardioid) to perform under pressure. True Diversity receiver in a metal housing and rackmount kit included.
- Excellent live sound featuring Sennheiser’s renowned evolution microphone capsules
- True diversity receiver with metal housing
- External antennas
- Automatic frequency management and synchronization via
- remote channel for easy setup
- Fully tunable over a wide range of UHF frequencies
- Rackmount kit included
- Up to 12 compatible channels
Receivers
-
-
Dimensions
- : approx. 200 x 42 x 127 mm, microphone: approx. 260 x 50 mm
-
-
- Weight
- : approx. 680g
-
- Power supply
- : 12 V DC nom. / 300 mA
-
- Housing
- : Metal, microphone: robust ABS
-
- AF frequency response
- : 50 to 16,000 Hz (–3 dB)
-
- Microphone
- : dynamic
-
- Frequency response
- : 50 to 16,000 Hz (–3 dB)
-
- THD, total harmonic distortion
- : ≤ 0.9%
-
- Pick-up pattern
- : cardioid
-
- Signal-to-noise ratio
- : ≥ 103 dBA
-
- RF output power
- : 10 mW
-
- Switching bandwidth
- : up to 24 MHz
-
- Operating time
- : approx. 10 hrs
-
- Modulation
- : wideband FM
-
- Output voltage
- : 1/4“ (6.3 mm) jack socket (unbalanced): +6 dBu, XLR socket (balanced): +12 dBu
-
- Frequency
- : 8 frequency banks, each with up to 12 factory-preset channels
-
- Frequency range
- : A: 548-572 MHzGB: 606-630 MHzB: 614-638 MHzC: 766-790 MHzD: 794-806 MHzE: 821-832 MHz, 863-865 MHzK: 925-937.5 MHz
-
- Sensitivity
- : < 3 μV at 52 dB(A)rms S/N
-
- Squelch
- : switchable from 3 dBμV to 28 dBμV (via Pilot Tone)
-
- Synchronization
- : 2.4 GHz, Low Power OQPSK (only active during synchronization)
-
- Line
- : 20 dB, switchable
-
- Input sensitivity
- : 1.5 mV / Pa
-
- Adjustment Range Transmitter
- : 0 to -30 dB, adjustable in 10 dB steps
-
- Audio adjustment range
- : 40 dB, adjustable in 5-dB steps
-
- Temperature Range
- : operation: 0°C to +40°Cstorage: –20°C to +70°C
-
- Receiver Principle
- : double superheterodyne
-
- Diversity principle
- : True Diversity
Microphone
-
- Weight
- : approx. 245g
-
- Power supply
- : 2 AA size batteries, 1.5 V
-
- AF frequency response
- : 80-14,000 Hz
- 1 receiver EM-XSW 2
- 1 handheld transmitter SKM 835-XSW
- 1 microphone clamp MZQ 1
- 1 power supply NT 12-5 CW
- 2 AA batteries
- 1 rackmount kit
- 1 pouch
- user manual
