TASCAM DR-V1HD เครื่องบันทึกเสียงดิจิตอล พกพา

฿11,900 (รวม VAT 7% แล้ว)

เช็ค Stock และราคาสินค้า กับเจ้าหน้าที่ก่อนสั่งซื้อทุกครั้ง
รับสินค้าภายใน 3 - 7 วัน (ขึ้นอยู่กับที่อยู่จัดส่งของลูกค้า)

สงวนสิทธิ์การเปลี่ยนแปลงข้อมูล ราคา ไม่แจ้งให้ทราบล่วงหน้า
สงวนสิทธิ์การรับผิดชอบเนื่องจากการพิมพ์ผิดพลาดต่างๆ

แชร์หน้านี้ :

เช็ค Stock และราคาสินค้า กับเจ้าหน้าที่ก่อนสั่งซื้อทุกครั้ง
รับสินค้าภายใน 3 - 7 วัน (ขึ้นอยู่กับที่อยู่จัดส่งของลูกค้า)
สงวนสิทธิ์การเปลี่ยนแปลงข้อมูล ราคา ไม่แจ้งให้ทราบล่วงหน้า
สงวนสิทธิ์การรับผิดชอบเนื่องจากการพิมพ์ผิดพลาดต่างๆ

แชร์หน้านี้ :

TASCAM DR-V1HD LINEAR PCM/HD VIDEO RECORDER

TASCAM DR-V1HD เครื่องบันทึกเสียงดิจิตอล พกพา DR-V1HD เครื่องบันทึก จากแบรนด์ TASCAM

The DR-V1HD is a combined HD Video Recorder and Linear PCM High-Quality Audio Recorder. TASCAM has revolutionized home and field recording for decades and with the release of the DR-V1HD has released another superior product. TASCAM has always been focused on creating easy to use, versatile products and with that thought process in mind, TASCAM provided a 180-degree rotating camera and microphone-set at the top of the unit along with specific feature sets and menu operations (“White Balance” features and still photography mode).

The DR-V1HD is encased in a sturdy and solid structure with an ergo dynamic design. TASCAM has continued their same sleek look as previously released handheld recorders and made sure to utilize rotary volume control for fine-tuned and quiet input level adjustments. The layout and controls were designed to decrease any unnecessary handling noise and produce stable filming operation.

Every fine detail was considered when TASCAM constructed the DR-V1HD. The mic placement structure was designed to rid any possible electrical noise and it records up to 96k/24-bit audio. TASCAM included their iconic “Variable-Speed-Audition,” and offered the ability to link any audio file on the device to still photographs. The DR-V1HD supplies HDMI out and a standard 1/4-20″ mount for use with a tri-pod. TASCAM has added a distinct and important new addition to their increasingly popular family of handheld/field recorders with the DR-V1HD.

คุณสมบัติ

MicroSD (64MB-2GB)/microSDHC (4GB-32GB) card slot (2GB microSD card included)
Built-in stereo condenser microphones
Supports 1280 x 720p HD mode
Camera and microphones rotate 180 degree
1x-4x digital zoom
Photography mode
Linear PCM recording up to 24bit/96kHz (24bit/48kHz with video)
Mini-HDMI connector
2.4inch TFT color LCD
MOVIE/AUDIO/PHOTO mode
Slide show (At PHOTO mode, interval time: 1-10sec, 1sec step)
Built-in monaural speaker (0.6W)
15mW + 15mW Headphones amplifier
White-balance selectable (AUTO,BULB LIGHT, FL LIGHT, STAGE LIGHT, SUNLIGHT, CLOUDY)
Auto-recording function (Recording starts automatically when input exceeds a set level)
Auto/manual track increment
Pre-recording buffer up to 2 sec.
Auto gain control and limiter
VSA (Variable Speed Audition) provide speed-control without changing pitch (50-150%)
Loop and Repeat playback
Playlist function
File editing function (Divide, Delete)
Automatic backlight power-off function
LCD display dimmer function
Audio replace after video shooting
Low cut filter (40/80/120Hz)
File name source selectable (date or word)
1/8″ external mic input (plug-in power available)
1/8″ external line input
1/8″ line/headphones output
Mini-B type USB2.0 port for data transfer to PC
Powered by 3 AA batteries or AC adapter (optional, PS-P520)
Tripod socket hole made by metal
Mini-USB cable included

ยี่ห้อ	TASCAM

สเปค

Recording Media	microSD/microSDHC-card
File System	FAT32,FAT16
Video Format	MOV
Video
Video Compression Method	MPEG-4 SP
Resolution	SD:640 x 480 / 30fps HD:1280 x 720 / 30fps
Audio
Recording Format	WAV
Sampling Frequency	44.1kHz / 48kHz
Bit Rate	16bit,24bit
Audio Format	WAV
Sampling Frequency	44.1kHz / 48kHz / 96kHz
Bit Rate	16bit,24bit
Still Picture Format	JPEG
Size	0.3M:640 x 480 0.9M:1280 x 720
Number of Channels
Video/Photo	1
Audio	2(Stereo)
Built-In Camera
Image Sensor	1/4-inch CMOS
Focal Length	39cm – ∞
Digital Zoom	1.0x – 4.0x
F Value	F2.8
White Balance	AUTO / BULB LIGHT / FL LIGHT / STAGE LIGHT/ SUN LIGHT/ CLOUDY
Built-In Microphone	Electret condenser microphone x 2(Stereo)
Polar Pattern	Cardioid
Maximum SPL	120dB SPL
Open circuit Voltage	-37dB at 1kHz(0dB=1V/Pa)RL=2kΩ、Vcc=3V
Impedance	1.4kΩ+/-30% at 1kHz(RL=2kΩ)
S/N Ratio	74dB Typ. at 1kHz(A-Weight)
Analog Audio Input/Output
MIC IN / LINE IN	Plug-in power
Connector	3.5mm(1/8″) Stereo mini jack
MIC IN	IINPUT SELECT set to MIC
Impedance	25kΩ
Input Level
GAIN LOW	-32dBV
GAIN MID	-48dBV
GAIN HI	-64dBV
Maximum Input Level
GAIN LOW	-16dBV
GAIN MID	-32dBV
GAIN HI	-48dBV
LINE IN	INPUT SELECT set to LINE
Impedance	22Ω
Input level	-10dBV(0.32V)
Minimum Input Level	-22dBV(0.08V)
Maximum Input Level	+6dBV(2.0V)
Phones / LINE OUT
Connector	3.5mm(1/8″) Stereo mini jack
Impedance	12Ω
Output Level	14dBV(10kΩ)
Maximum Output Level	+2dBV(10kΩ)
Maximum Output	15mW + 15mW(32Ω)
LCD Monitor
Size	2.4″ Color TFT LCD
Resolution	240 x 320
Backlight	HIGH / LOW / ALL OFF
Built-in Speaker	0.6W,Monaural
USB
Connector	Mini-B
Format	USB2.0 HIGH SPEED Mass Storage Class
HDMI
Connector	miniHDMI(Type C)
Tripod Mounting Thread	1/4-inch
Power Supply	Three AA batteries (Alkaline or Ni-MH) TASCAM PS-P520 AC adaptor (sold separately)
Power Consumption	0.9W (Maximum)
Dimensions	70(W)×131(H)×28(D)mm
Weight	157g (Batteries not included)
Operating temperature range	0 – 35℃
Accessories	2GB microSDHC card, Mini USB Cable, 3 “AA” Batteries
Audio performance
Frequency response	20Hz – 20kHz +1/-3dB(44.1kHz、LINE IN→LINE OUT、JEITA) 20Hz – 22kHz +1/-3dB(48kHz、LINE IN→LINE OUT、JEITA) 20Hz – 42kHz +1/-3dB(96kHz、LINE IN→LINE OUT、JEITA)
THD	0.02% or less(44.1k / 48k / 96kHz、LINE IN→LINE OUT、JEITA)
S/N比	90dB or more(44.1k / 48k / 96kHz、LINE IN→LINE OUT、JEITA)
