ตู้ลำโพง TURBOSOUND TVX152 15 นิ้ว 2 ทาง 2000 วัตต์ ตอบสนองความถี่ 60 Hz – 20 kHz ±3 dB และ 50 Hz – 20 kHz –10 dB TURBOSOUND TVX152 ลำโพง 15 นิ้ว จากแบรนด์ TURBOSOUND
TURBOSOUND VENUE TVX152
2 Way 15″ Full Range Loudspeaker for Portable PA and Installation Applications
- 2 way full range loudspeaker for portable PA and installation applications
- 500 Watts continuous, 2,000 Watts peak power
-
Ideal for FOH, side and drum fill applications
- Carbon fibre loaded 15″ low frequency driver with inside/outside wound coil
- Aluminium dome 1″ neodymium motor compression driver
-
Switchable passive/bi-amp operation for flexibility of use
- Low distortion waveguide provides 70° H x 70° V dispersion
- 15 mm (5/8″) birch plywood enclosure with hard wearing semi matt black paint finish
- Rugged powder coated perforated steel mesh grille
- Dual angle pole mount for accurate audience coverage
-
Durable handles for easy lifting and carrying
- Multiple internal rigging points for install applications
- Neutrik speakON* NL4 connectors for reliable long life operation
-
10-Year Warranty Program*
- Designed and engineered in the U.K.
TVX152
2 Way 15″ Full Range Loudspeaker for Portable PA and Installation Applications
Technical Specifications
System
Frequency Response | 60 Hz – 20 kHz ±3 dB 50 Hz – 20 kHz –10 dB |
Nominal Dispersion | 70° H x 70° V @ -6 dB points |
Directivity Factor (Q) | 9.4 |
Directivity Index (DI) | 9.7 |
Power Handling (IEC) | |
Passive | 500 W continuous, 2,000 W peak |
Bi-amp | LF: 500 W continuous, 2,000 W peak HF: 40 W continuous, 160 W peak |
Sensitivity | 97 dB (1 W @ 1 m) |
Maximum SPL | |
Passive | 124 dB continuous, 130 dB peak |
Bi-amp | LF: 124 dB continuous, 130 dB peak HF: 122 dB continuous, 128 dB peak |
Impedance | |
Passive | 8 O |
Bi-amp | LF: 8 O; HF: 6 O |
Crossover Type | Passive / bi-amp, switchable |
Components | 1 x 15″ (394 mm) LF driver 1 x 1″ (25 mm) HF compression driver |
Enclosure
Connectors | 2 x Neutrik speakON* NL4 |
Wiring | |
Dimensions (H x W x D) | 701 x 432 x 470 mm (27.6 x 17 x 18.5″) |
Net Weight | 26.4 kg (58.1 lbs) |
Construction | 15 mm (5/8″) birch plywood |
Finish | Semi matt black paint |
Grille | Powder-coated perforated steel |
Flying Hardware | M12 x 12 points |
