ESi100D

ESi200D

ESi1020

Audio

Speaker type.

2 Way full-range active speaker

Drivers.

LF 10″woofer,

HF 3.2″titanium driver

LF 12″woofer,

HF 3.5″titanium driver

LF 10″woofer,

HF 1″ compression driver

Frequency response

60Hz-20KHz

50Hz-20KHz

55Hz – 20KHz

Sensitivity 1w/1m

94dB

Built-in mixer

5 channel

7 channel

Power Output.

60W / 120W (Max)

150W / 300W (Max)

120W / 240W (max)

Amplifier

Bi-Amplifier

CLASS-D

Amplifier

CLASS-D

Bi-Amplifier

CLASS-D

Protection.

Short circuit, over-current, overload protection

Operating voltage

AC : 100-240V, DC : 18V

AC : 100-240V, DC : 12V

AC: 100-240V DC: 24V (12V*2)

Media Player.

SD-Card  USB Port

Supported file formats: MP3, WMA

Bluetooth

Bluetooth Range

10 Meter

Wireless microphone.

Frequency range Group A

803.2MHz

803.2 ～ 805.8 MHz

Frequency range Group B

805.8MHz

803.2 ～ 805.8 MHz

Channel number

32 Channels (16*2)

Receivers

Dual UHF wireless receiver

Transmitters.

Dual Handheld microphone transmitters

Transmitter power.

10mw

Distance Range.

50 Meter sing of line

20 – 50 Meter sing of line

Wireless Mic Power.

2 AA 1.5V batteries

Battery.

Battery Type.

18V DC, 4.5Ah lead acid batteries

12V DC, 7Ah lead acid batteries

24V DC, 5Ah/20Hr lead acid batteries

Battery life.

Up to 8-10 Hours at half power

Up to 6-8 Hours at half power

Up to 12 Hours at half power 4 hours at max power.

Recharge Time.

Approximately 6 hours

Approximately 5 hours

Approximately 10 hours

General.

Cabinet material.

ABS

polypropylene (PP)

Mounting Socket.

Standard 35 mm

Dimensions.(W*H*D)

320 x 490 x 260 mm

390 x 570 x 330 mm

360 x 560 x 303 mm

Weight.

13.5 Kg

18 Kg

17.5 kg
