เทียบสเปค!! ตู้ลำโพง ยอดฮิต 12 นิ้ว และ 15 นิ้ว

BRAND

Model

EON 612

CP12

Speaker type

12” Two-way active loudspeaker

12” Two-way active loudspeaker

Frequency range

-10 dB 48 Hz – 20 kHz

-10 dB 47 – 20 kHz

Nominal coverage

H 100°

H 75°

V 60°

V 75°

Components

LF 12”

LF 12”

HF 1”

HF 1.4”

Output power

1000W.Peak: 700 W (LF), 300 W (HF)

1000W.Peak: 800 W (LF), 200 W (HF)

Amplifier

Class D

Class D

Maximum output SPL

126 dB

126 dB

I/O connectors

2 INPUT COMBO JACK,

2 INPUT COMBO JACK,

1 TRS 3.5 MINIJACK

1 OUTPUT XLR

1 OUTPUT XLR

Dimensions

W 380 mm

W 350 mm

H 664 mm

H 516 mm

D 316 mm

D 323 mm

Net weight

14.96 kg (33 lbs)

13.7 kg (30.3 Ibs)

Others

Bluetooth control with Applicaton

Remote control via smartphone, tablet android,ios

DSP select 6 preset

Material

Polypropylene

Polypropylene

Application

Main, Monitor

Main, Monitor

ราคา

21,900.-

21,690.-

BRAND

Model

ZLX-12BT

iX12

Speaker type

12” Two-way active loudspeaker

12” Two-way active loudspeaker

Frequency range

-10 dB 50 Hz – 20 kHz

-10 dB 42Hz – 20kHz

Nominal coverage

H 90°

H 80°

V 60°

V 60°

Components

LF 12”

LF 12”

HF 1”

HF 1”

Output power

1000W

1000W

Amplifier

Class D

Class D (LF) / Class AB (HF) Bi-Amp

Maximum output SPL

126 dB

125dB

I/O connectors

2 INPUT COMBO JACK,

2 INPUT COMBO JACK

1 INPUT TRS 3.5 MINI JACK

1 OUTPUT XLR

1 OUTPUT XLR

Dimensions

W 356 mm

W 370 mm

H 610 mm

H 609 mm

D 356 mm

D 370 mm

Net weight

14.96 kg (33 lbs)

19.4kg (42.8lbs)

Others

Bluetooth Audio Streaming

with QuickSmart DSP

Bluetooth Audio Streaming

Bluetooth control with Applicaton,Remote Control via iPhone/iPad # ios

Material

Polypropylene

Polypropylene

Application

Main, Monitor

Main, Monitor

ราคา

24,990.-

18,500.-

BRAND

Model

EON 615

DXR15

Speaker type

 15” Two-way active loudspeaker

 15” Two-way active loudspeaker

Frequency range

-10 dB 39 Hz – 20 kHz

-10 dB 49Hz – 20kHz

Nominal coverage

H 90°

 H 90°

V 60°

V 60°

Components

LF 15”

LF 15”

HF 1”

HF 1.4”

Output power

1000W.Peak: 700 W (LF), 300 W (HF)

1100W.Peak: 950 W (LF), 150 W (HF)

Amplifier

Class D

Class D

Maximum output SPL

127 dB

133dB

I/O connectors

2 INPUT COMBO JACK,

2 INPUT COMBO JACK

1 INPUT XLR AND THRU 1 XLR (Parallel)

2 INPUT PHONE

2 INPUT RCA

1 OUTPUT XLR

1 OUTPUT XLR ( Link)

Dimensions

W 380 mm

W 445 mm

H 664 mm

H 700 mm

D 316 mm

D 380 mm

Net weight

17.69 kg (33 lbs)

22.5kg (42.5 lbs)

Others

Bluetooth control with Applicaton

Remote control via smartphone, tablet #android,ios

D-CONTOUR: FOH/MAIN, MONITOR, OFF

Material

Polypropylene

ABS (Matte Finish, Black)

Application

Main, Monitor

Main, Monitor

ราคา

24,900.-

36,550.-

BRAND

Model

ZLX-15BT

iX15

Speaker type

 15” Two-way active loudspeaker

 15” Two-way active loudspeaker

Frequency range

-10 dB 42 Hz – 20 kHz

-10 dB 39Hz – 20kHz

Nominal coverage

 H 90°

 H 75°

V 60°

V 55°

Components

LF 15”

LF 15”

HF 1”

HF 1”

Output power

1000W

1000W

Amplifier

Class D

Class D (LF) / Class AB (HF) Bi-Amp

Maximum output SPL

127 dB

126dB

I/O connectors

2 INPUT COMBO JACK,

2 INPUT COMBO JACK,

1 INPUT TRS 3.5 MINI JACK

1 OUTPUT XLR

1 OUTPUT XLR

Dimensions

W 426 mm

W 450 mm

H 685 mm

H 711 mm

D 383 mm

D 381 mm

Net weight

17.3 kg (38.0 lbs)

22.4kg (49.4lbs)

Others

Bluetooth Audio Streaming

with QuickSmart DSP

Bluetooth Audio Streaming

Bluetooth control with Applicaton,Remote Control via iPhone/iPad # ios

Material

Polypropylene

Polypropylene

ราคา

30,390.-

20,890.-
